Medium Length LHD 6X4 Tipper Dump Truck SINOTRUK Golden Prince 290HP For Mining

Medium Length LHD 6X4 Tipper Dump Truck SINOTRUK Golden Prince 290HP For Mining

  • Medium Length LHD 6X4 Tipper Dump Truck SINOTRUK Golden Prince 290HP For Mining
  • Medium Length LHD 6X4 Tipper Dump Truck SINOTRUK Golden Prince 290HP For Mining
  • Medium Length LHD 6X4 Tipper Dump Truck SINOTRUK Golden Prince 290HP For Mining
  • Medium Length LHD 6X4 Tipper Dump Truck SINOTRUK Golden Prince 290HP For Mining
Medium Length LHD 6X4 Tipper Dump Truck SINOTRUK Golden Prince 290HP For Mining
تفاصيل المنتج:
Place of Origin: China
اسم العلامة التجارية: SINOTRUK Golden Prince
إصدار الشهادات: ISO/3C/BV/IFA/SGS
Model Number: ZZ3251M3641W
شروط الدفع والشحن:
Minimum Order Quantity: 1 Unit
الأسعار: USD35000-USD37000/UNIT)negotiation
Packaging Details: Nude or Waxing in Roro or bulk ship
Delivery Time: 25 working days after received your advance payment
Payment Terms: L/C, T/T, Western Union
Supply Ability: 3,000units per month
اتصل
مفصلة وصف المنتج
Product Name: Tipper Dump Truck Model: ZZ3251M3641W
Drive type: LHD 6X4 Emission Standard: Euro 2
Engine: WD615.87, 290HP Cargo body: 5400*2300*1500mm
Loading capacity: 30-40tons Thickness of cargo body: floor:8mm, side:6mm
Steering: D50, ZF Cabin: L2000 medium length
تسليط الضوء:

heavy dump truck,sinotruk howo dump truck

,

sinotruk howo dump truck

Dump Truck SINOTRUK Golden Prince 290HP 25-30ton 10-25CBM ZZ3251M3641W for mining



Description:



SINOTRUK Golden Prince Tipper Truck 290HP 25-30tons 10-25CBM ZZ3251M3241W

Golden Prince series Tipper Dump Truck adopt German MAN L2000 series cab technology,

Kim Prince cab car LAN communication system features vehicle electrical system of the two generation of intelligent control system using the international standard (CAN bus), intelligent control system software integration in high technology (ACU), the digital control system (ASIC) control, the electrical system of the instrument function, and function of self driving.



Golden Prince cab dust dust separation valve maintenance regularly to empty the intake pipe separation valve. In the accumulation of dust on my case, cleaning once a week. The dust special serious, are eliminated every day. To empty, compression rubber bellows seal. Accurate installation is very important.

What are the cab parts: (1) the cab shell (2) cab frame (3) the whole car parts (4) trim (5) glass steel tank (6)







Specification:



Dump Truck SINOTRUK Golden Prince 290HP 25-30ton 10-25CBM ZZ3251M3641W for mining

Model ZZ3251M3641W
Drive Type 6×4
Engine

WD615.87 , 290HP( Euro II)

6 cylinder in-line with water cooling, turbo-charging & inter-cooling,4 stroke electronic fuel injection diesel engine

Displacement : 9.726L

Cabin L2000  medium length cab(with one sleeper, air-conditioner and new-style seat)
Transmission HW15710(10 forwards & 2 reverses)
Front Axle 1×HF9 ( 9 Tons)
Driving Axle HC16, 16Tons
Steering D50 hydraulic steering with power assistance.
Clutch Single-plate dry coil-spring clutch, diameter 430mm, hydraulically operating with air assistance
Rim/ Tire 11.00R20,12.00R20,12.00R24 Radial tire
Wheel base 3600+1350(mm)
Overall dimension 7920×2496×3250(mm)
Cargo body

5000×2300×1500(mm),Bottom:8mm, Side:6mm

The curb weight 11550(Kg)
Gross weight 25000 kg
Max. speed 75km/h
Color White, red, green, golden and so on.




Applications:



It used for Mining industry, Construction business, docks and so on.



Competitive Advantage:



10)competive price, cost-effective

2) Reliable quality

3) good after sales service
4)quick and efficient spare parts supply bring you more convenient
5)fast delivery time, we can arange production according to your needs exactly and

quickly

6) professional import and export dealing precedure, make customs clearance more high efficiency

7)all kinds of cargo body structure can be designed and produced according to your request, make it have light curb weight , high rigidity , high loading capacity
8)using the high strength steel, make it has a long service life
9)we can do the designs according to the your requirement and idea.
10)we can offer you the high quality & reasionalble price
11)we can offer your a good after-sell service
12)we have strong professinal design team
13)promptly delivery. small order is welcome
14)the key parts adopt the world's top technology products
15)based on strong technical support and top level technology make the trucks with high

quality and more reliable
