Large Capacity Diesel Semi Trailer Fuel Tanker Truck Tri - Axle 50 - 80 Tons

Large Capacity Diesel Semi Trailer Fuel Tanker Truck Tri - Axle 50 - 80 Tons

  • Large Capacity Diesel Semi Trailer Fuel Tanker Truck Tri - Axle 50 - 80 Tons
  • Large Capacity Diesel Semi Trailer Fuel Tanker Truck Tri - Axle 50 - 80 Tons
  • Large Capacity Diesel Semi Trailer Fuel Tanker Truck Tri - Axle 50 - 80 Tons
  • Large Capacity Diesel Semi Trailer Fuel Tanker Truck Tri - Axle 50 - 80 Tons
Large Capacity Diesel Semi Trailer Fuel Tanker Truck Tri - Axle 50 - 80 Tons
تفاصيل المنتج:
Place of Origin: China
اسم العلامة التجارية: SINOTRUK
إصدار الشهادات: ISO/3C/BV/IFA/SGS
Model Number: 3 Axles 50000 Liters Oil carrying Trailer
شروط الدفع والشحن:
Minimum Order Quantity: 1 Unit
الأسعار: Negotiation
Packaging Details: Nude or Waxing in Roro or bulk ship, or by 40GP, 40HQ,40FR and so on
Delivery Time: 20 working days after received your advance payment
Payment Terms: L/C, T/T, Western Union
Supply Ability: 4,000units per month
اتصل
مفصلة وصف المنتج
Product Name: Semi Trailer Oil Tank Truck Model: 3 Axles 50000Liters
Fifth Wheel: #50, #90 Loading capacity: 50-80tons
Tank Capacity: 45-60CBM Thickness of Tank body: 4mm 5mm 6mm Optional
Axles: 3X13 tons,3X16 tons Material: Carbon steel or Mn steel
تسليط الضوء:

Semi Trailer Dump Truck,hydraulic flatbed trailer

,

hydraulic flatbed trailer

HOWO A7 Large Capacity Tri - Axle Diesel Tanker Semi Trailer Truck 50 - 80Tons​





Description:



HOWO A7 Large Capacity Tri - Axle Diesel Tanker Semi Trailer Truck 50 - 80Tons

Semi Trailer Tank Truck is divided into two parts, oil tank part and a support body

skeleton or driving part is traction head connecting Trailer tanker, compared with

ordinary single type tank truck, semi-trailer tank truck can effectively improve the

transportation efficiency. In the same tonnage and reduce  the transportation cost,

saving fuel. The rear of Semi trailer tank is approximately the same,which have 2 Axles

and 3 Axles, according to the need to choose  the traction head.



According to customer's special requirements for the use of centrifugal pumps, gear

pumps, stainless steel pumps, with large flow, fast suction speed and so on.

Tanker measurement can choose single count, flow meter double counting, assembly tax

controlled computer refueling machine, installed 10 to 15 meters automatic telescopic

return reel, equipped with a gas gun. Edible oil can be used edible oil computer meter

to measure.



Tank body using 4mm or 6mm quality carbon steel according to the national standard, the

shape of oval or square round tank, can be installed 1-4 kinds of oil. Also can produce

heating insulation series tank.



The tank design using multi channel swash plate. Using high pressure gas leakage

detection, the tank  has characteristics of high strength, stable center of gravity, high

vehicle safety and stable and so on.





Specification:



HOWO A7 Large Capacity Tri - Axle Diesel Tanker Semi Trailer Truck 50 - 80Tons
Model 3 Axles 50000Liters
Axle

FUWA brand, 13ton, 3 Sets

Main beam

Beam height: 500mm

Upper plate: 10mm

Double Middle plate: 6 mm

Down plate: 12mm

Tank Body Thickness

4mm, 5mm, 6mm optional

Material

Carbon steel or Mn steel

Gross vehicle weight

65000kgs

King pin

#90

Support leg

JOST Standard 28T

Suspension

Normal suspension

Thickness leaf spring

10/10/10

Tire/Rim

1200R20, 13pcs, 8.5, 12 pcs

Brake Chamber

Standard 6 pcs

Spare wheel carrier

2 pcs

Tool box

1 pcs

Electrical System

Chinese standard 24C lighting system

Side Maker Lamp

LED lamp

Painting

Polyurethane Paint

Overall dimension

14100×2500×3780(mm)

Color White, red, green, golden and so on.




Applications:



It’s suitable for storage and carrying all kinds of Oils .



Competitive Advantage:



1) it has higher safety and running efficiency.

2) Optimized structure design, let it have lower self weight, but more stonger

3) excellent appearance of cabin, safety, reliable

4) low fuel consumption

5) the key parts adopt the world's top technology products

6) based on strong technical support and top level technology make the trucks with high

    quality and more reliable

7) competitive price, cost-effective

8) quick and efficient spare parts supply bring you more convenient

9) fast delivery time, we can arrange production according to your needs exactly and Quickly

10) professional import and export dealing procedure, make customs clearance more high efficiency



Large Capacity Diesel Semi Trailer Fuel Tanker Truck Tri - Axle 50 - 80 Tons 0Large Capacity Diesel Semi Trailer Fuel Tanker Truck Tri - Axle 50 - 80 Tons 1
