Place of Origin: | China |
اسم العلامة التجارية: | SINOTRUK HOKA |
إصدار الشهادات: | ISO/3C/BV/IFA/SGS |
Model Number: | ZZ3255N3646B1 |
Minimum Order Quantity: | 1 Unit |
---|---|
الأسعار: | USD38000-USD42000/UNIT)negotiation |
Packaging Details: | Nude or Waxing in Roro or bulk ship |
Delivery Time: | 25 working days after received your advance payment |
Payment Terms: | L/C, T/T, Western Union |
Supply Ability: | 3,000units per month |
Product Name: | Tipper Dump Truck | Model: | ZZ3255N3646B1 |
---|---|---|---|
Drive type: | LHD 6X4 | Emission Standard: | Euro 2 |
Engine: | WD615.69, 336HP | Cargo body: | 5600*2300*1500mm |
Loading capacity: | 30-40tons | Transmission: | HW15710 |
Steering: | ZF Brand | Hydraulic cylinder: | Euro brand |
إبراز: | heavy dump truck,sinotruk howo dump truck,sinotruk howo dump truck |
SINOTRUK Dump Truck LHD 371HP 10 wheels 20CBM 30 - 40ton HYVA Hydraulic cylinder
Description:
SINOTRUK Dump Truck LHD 371HP 10 wheels 20CBM 30 - 40ton HYVA Hydraulic cylinder
HOKA brand is the Leader of Heavy Duty Truck Industry Driving King On The Road.
The solebar level upgrading of new high strength materials, tensile strength more than 820Mpa. single beam, 300 x 90 x 8,90mm wing width of the frame for the flexural torsional strength greater, chassis performance is more stable, the bearing capacity is better than that of the original frame and reduce the vehicle weight about 100 kilograms.
Electric cab lift system, reduce labor intensity, easy to vehicle maintenance
The application of ergonomics for the latest achievements in design of the cab, comfortable environment, can ensure the occupants full of go;
fully using the latest Weiboke ABS technology upgrades, increased ASR+EBL+TPM in fully meet the basis of European regulations, to ensure the safety of the vehicle, the maximum.ASR - EBL - to avoid skidding; braking force distribution is better; TPM -- Survey of tire pressure changes at any time.
Adopt LED taillight, high brightness and long service life and low failure, night driving safer.
The new EVB engine braking technology is the guarantee of long road vehicle running, effectively control the speed and increase the braking power, reduce brake frequency, reduce wear of vehicle brake and tire, vehicle to improve the service life and traffic safety will make drivers more assured.
The full use of front disc and drum brake, shorten the braking distance, to ensure traffic safety.
The standard tubeless tire has light weight, good balance, low heat, wear resistance, safety and other advantages, because of low rolling resistance, the fuel can be saved about 5%.
Specifications:
SINOTRUK Dump Truck LHD 371HP 10 wheels 20CBM 30 - 40ton HYVA Hydraulic cylinder | ||||
Model | ZZ3257N3647B1 | |||
Drive Type | 6×4 | |||
Engine |
|
|||
Cabin | A7-W lengthened cab(with one sleeper, air-conditioner and new-style seat) | |||
Transmission | HW15710(10 forwards & 2 reverses) | |||
Front Axle | 1×HF9 ( 9 Tons) | |||
Driving Axle | HC16, 16Tons | |||
Steering | ZF8118 hydraulic steering with power assistance. | |||
Clutch |
Single-plate dry coil-spring clutch, diameter 430mm, hydraulically operating with air assistance |
|||
Rim/ Tire | 11.00R20,12.00R20,12.00R24 Radial tire | |||
Wheel base | 3600+1350(mm) | |||
Overall dimension | 8375×2496×3450(mm) | |||
Cargo body | 5600×2300×1500(mm),Bottom:8mm, Side:6mm | |||
The curb weight | 12300(Kg) | |||
Gross weight | 25000 kg | |||
Max. speed | 75km/h | |||
Color | White, red, green, golden and so on. |
Applications:
working for Mining industry, Construction business, docks, to transport soil, sand, stones and so on.
Competitive Advantage:
1) The front windshield and the combination of large mirrors to eliminate blind spots, excellent vision;
2) on the sleeper with safety protection net;
3)Electric cab lift system, reduce labor intensity, facilitate vehicle maintenance.
4)low fuel consumption
5) strong enough engine
6)with all kinds of truck model, which can fulfil your requirement
7)the key parts adopt the world's top technology products
8)based on strong technical support and top level technology make the trucks with high
quality and more reliable
9)quick and efficient spare parts supply bring you more convenient
10)Optimized cargo body structure,light weight,high rigidity,large loading capacity
11)Using the high strength steel,it has long service life
12)Optimized the sealing structure has the better sealing effect.
13)Multiple box structures and device selections
14)The intelligent hydraulic control system helps to avoid error operation, it has higher safety and
running efficiency.
15)fast delivery time, we can arange production according to your needs exactly and
quickly
16) professional import and export dealing precedure, make customs clearance more high efficiency
15)competive price, cost-effective
